Camera Cage for Sony FS5

30 Day Return Policy Shop with confidence with our updated return policy

$479.00$650.00

Clear
SKU: ES-T14 Category: Tags: ,

Description

Arm your camera with this Tilta camera cage specifically designed for the Sony FS5.

The cage’s top plate fits snugly around the Sony FS5 top handle and includes 15mm LWS rod adapters on the front and back end to allow you to mount accessories in a variety of ways.

The Battery Plate for Sony FS5 Camera Cage (available in either gold mount or V-mount) has a 15mm LWS rod adapter that can be placed on either the top or bottom of the plate to allow you to either mount it off of 15mm LWS rods from the top plate or bottom shoulder pad. The battery plate provides several different DC and P-tap outputs to allow you to power accessories.

On the bottom of the cage is a Sony VCT-U14 compatible baseplate that allows you to attach various accessories via 15mm LWS rods on either the front or back side of the plate. The plate also has an ergonomic shoulder pad on the bottom so that you can quickly and easily detach from the VCT-U14 plate and be shoulder mount-ready in no time. The plate also has Arri Standard Rosette connections on either side to allow you to attach handles for handheld operation as well as a built-in lens adapter support bracket.

An extendable rosette arm and extension cable are also included so that you can extend out and adjust the mounting position of your Sony FS5 handle to your liking.

  1. (1) Top handle plate
    • ¼”-20 and ⅜”-16 screw holes
    • (4) 15mm LWS rod mounts (2 in front, 2 in back)
  2. (1) Sony FS5 bottom plate
  3. (1) Sony VCT-U14 quick release baseplate
    • (1) Shoulder pad
    • (2) Arri Standard Rosette connections
  4. (1) Lens adapter support
  5. (1) Sony FS5 battery plate  (available in V-mount or gold mount)
    • (1) 15mm LWS rod adapter
    • (2) 12V DC outputs
    • (1) 8V DC output
    • (1) 14.8V P-tap output
  6. (1) Extendable rosette arm for Sony FS5 handle
  7. (1) Sony FS5 handle mount adapter
  8. (2) 15mm x 200mm rods
  9. (2) 15mm x 100mm rods

Color: Black
Materials: Aluminum-alloy
Rod System: 15mm LWS
Power Output: Tilta Battery Plate DC and P-tap ports — 3 Amps max. each, 7 Amps max. total
